| Vehicle information Items | Technical parameters |
| Chassis model | QL1040A6FAY |
| Brand of chassis | ISUZU 4x2 |
| Hand driven | Left hand |
| Overall dimensions ( L * W * H) | 5995×1960×3000m |
| Lifting height | 27 meters |
| Lifting weight | 200 KGS |
| Wheel base | 2795 mm |
| Tire | 6.50R16LT 10PR (6+1 spare) |
| Engine | 4KH1CN5LS |
| Emission Standard | Euro V |
| Transmission | MSB Five speed |
| Traction system | 4x2 |
| Number of axles | 2 |
| Electric system | 24V |
| Displacement | 72kw/2999ml |
| Engine horsepower | 98 hp |
| Axle load | 2.0tons (front)/4-4.8tons (rear) |
| Approach angle /Departure angle | 20/12 |
| Cabin seat | 2 |
| Max.speed | 103 km/h |
| Operation control system | Steering wheel |
| Equipment | Air-condition/Radio/USB/Power steering |
| Standard Equipment | Equipped with engine device, emergence power units | ||
| Technical parameters
| Boom | Five hexagonal arms, synchronous telescopic | |
|
| Max operation height | 27 meters | |
|
| Max operation rear | 21 meters | |
|
| Max lifting height side | 18 meters | |
|
| Working platform rating loading | 200 kg | |
|
| Working platform dimension | 1600×650×1150mm | |
|
| Degree of the overturn: | 360°turning(left or right) | |
|
| Standing Legs | Front V and rear V single leg | |
|
| Leg span | Horizontal | 5500 mm |
|
|
| vertical | 5500 mm |
